Basic measuring kit Metriso B530 with 850 electrodes

The Metriso® B530 Basic measuring kit from Warmbier is suitable for measuring point-to-point resistances and leakage resistances in the ESD zone.

• Measuring voltage/measuring current: Ohm range: 1 mA < I < 1.3 mA / High impedance range: DC voltage 10 V, 100 V and 500 V
• Measuring range: Low impedance range: 1 to 10 kOhm / High impedance range: 1 kOhm to 199 GOhm
• Operating mode: battery operation
• Electrodes: 2x Model 850 (weight 2.27 kg / ø 63.5 mm) with conductive contact rubber (black); 1x hand electrode Model 45
• complies with DIN EN 61340-4-1, DIN EN 61340-2-3, DIN EN 61340-4-5

Item no.	WL47494
Model	7100.B530.MK.850
Manufacturer	WARMBIER
Manufacturer article no.	7100.B530.MK.850
Sales unit	1 set
Content unit	1 set
Compatible for cleanroom	no
ESD compliant	yes
GPSR manufacturer data	Wolfgang WARMBIER Untere Gießwiesen 21 DE-78247 Hilzingen www.warmbier.com
