ESD insert for Euro box 1 and 2, 7 wells, 362 x 263 x 43 mm

ESD insert for Euro box 1 and 2, 7 wells, 362 x 263 x 43 mm #2

ESD insert for Euro box 1 and 2, 7 wells, 362 x 263 x 43 mm #thumbnail-1

ESD insert for Euro box 1 and 2, 7 wells, 362 x 263 x 43 mm #thumbnail-2

Discover the ESD insert from Licefa, available at Weidinger.eu, which has been specially developed for electronics production. With dimensions of 362 x 263 x 43 mm and seven practical recesses (each 189 x 35 x 41 mm), this insert offers optimum protection for sensitive electronic components. Made of dissipative polystyrene (PS) in elegant black, it ensures a reliable conductivity value in the dissipative range of >1 x 10⁴ to <1 x 10¹¹ ohms. This ESD insert is compatible with Euroboxes 1 and 2, making it a versatile solution for your storage and transportation needs. The article number 2425990 facilitates quick identification and ordering. Rely on the quality and functionality of this insert to organize your electronic components safely and efficiently.

• Material: dissipative PS (polystyrene)
• Conductance: (dissipative >1 x 10⁴ to <1 x 10¹¹ Ohm)
• Color: black
• External dimensions: 362 x 263 x 43 (L x W x H)
• Recesses: 7 (189 x 35 x x41)
• Suitable for Euro boxes 1 and 2

Item no.	WL85637
Alternative article name	T2-107-6-10
Manufacturer	LICEFA
Manufacturer article no.	2425990
Length	362 mm
Width	263 mm
Height	43 mm
Sales unit	1 piece
Content unit	1 piece
Length (recess)	189 mm
Width (recess)	35 mm
Height (recess)	41 mm
Number of recesses	7
Colour	black
Typical surface resistance (Rpp)	dissipativ >1 x 10⁴ - <1 x 10¹¹ Ohm
Material storage boxes	plastic
ESD compliant	yes
GPSR manufacturer data	LICEFA GmbH & Co.KG Lemgoer Strasse 11 DE-32108 Bad Salzuflen www.licefa.de
